Hyundai Sonata LF 2014-2019 Service Manual: Audio Remote Control (Sonata Sports) Repair procedures
Inspection
1.
Check for resistance between terminals in each switch position (LH).
[LH : Audio + Hands free]
SwitchConnector TerminalResistance(±5%)SEEK Up4-5430 ?SEEK Down1.11 k?MUTE3.11 k?Volume (+)4.61 k?Volume (-)6.81 k?Voice10.71 k?SEND18.91 k?END40.91 k?
2.
Check for resistance be ...
Hyundai Sonata LF 2014-2019 Service Manual: Electric WGT Control Actuator Description and Operation
Desrcription
The Electric WGT Control Actuator is installed on the
turbocharger.It operates the vain in the Waste Gate Turbocharger (WGT)
and regulates the compressed air amount by the ECM's PWM signal. This
actuator consists of a DC motor which actuates the vane, a 2-step gear
which incr ...
