Speaker Repair proceduresInspection 1. Troubleshooting for Speaker (1) Basic inspection of speaker Inspect the sound from speaker after verifying that the speaker mounting screws is removed and the wiring connector is connected precisely to remove vibration transmitted from body trims and surrounding parts...
AUX jack Description and OperationDescription The multimedia jack on the console upper cover is for customers who like to listen to external portable music players like the MP3 etc...
Components and Components Location Components [General Type] 1. Roof trim2. Sunvisor [LH]3. Sunvisor [RH]4. Assist handle bracket [Panorama Sunroof Type] 1. Roof trim2. Sunvisor [LH]3. Sunvisor [RH]4. Assist handle bracket Sunvisor Components and Components Location Component Location 1...
Circuit Diagram • COM signal - When controlling the voltage generated, the ECM sends the target voltage data to the alternator via a PWM signal.(High voltage: 4V or higher, low voltage: 2V or lower) • FR signal - The transistor activation signal inside the alternator monitors the voltage generated by the alternator to control the excitation current before it sends the FR signal to the ECM...
