Hyundai Sonata LF 2014-2019 Service Manual: AVN Remote Controller Repair procedures
Inspection
1.
Check for resistance between terminals in each switch position (LH).
[LH : Audio + Hands free]
SwitchConnectorTerminalResistance(±5%)SEEK Up2-5430 ?SEEK Down1.11 k?MODE2.11 k?MUTE3.11 k?Volume (+)4.61 k?Volume (-)6.81 k?Voice10.71 k?SEND18.91 k?END40.91 k?
2.
Check for res ...
Hyundai Sonata LF 2014-2019 Service Manual: Auto Head Lamp Leveling Unit Repair procedures
Inspection
1.
Ignition "ON".
2.
Turn on the head lamp switch.
3.
Check for operation. If the aim of the head lamps changes smoothly when the head lamp leveling switch is turned.
4.
If the operation does not work well, inspect the connector and terminals to be sure they are all making ...
