Hyundai Sonata LF: Timing System / Timing Chain Cover Components and Components Location

Front Oil Seal Repair procedures

Removal and Installation 1. Crankshaft damper pulley. (Refer to Timing System - "Damper Pulley") 2. Remove the front oil seal.     Using the SST (09455-21200), reassemble the timing chain cover oil seal...

Timing Chain Cover Repair procedures

Removal     • Use fender covers to avoid damaging painted surfaces. • To avoid damage, unplug the wiring connectors carefully while holding the connector portion...
