Hyundai Sonata: Light Bulbs / License Plate Light Bulb Replacement
.jpg)
1. Loosen the lens retaining screws with a philips head screwdriver.
2. Remove the lens.
3. Remove the bulb by pulling it straight out.
4. Install a new bulb.
5. Reinstall the lens securely with the lens retaining screws.
High Mounted Stop Lamp
1. Remove the rear seat cushion assembly.
2. Remove the rear seat back assembly.
3. Slightly remove the rear door weather-strip.
4. Remove the rear door scuff trim.
5. Remove the rear pillar trim.
6. ...
Interior Light Bulb Replacement
Map lamp and Room lamp
If the LED lamp does not operate, have the vehicle checked by an authorized HYUNDAI
dealer.
Map lamp, Room lamp, Vanity mirror lamp and Luggage room lamp
1. Using a flat-head ...
