Hyundai Sonata LF: Dual Clutch Transmission Control System / Input shaft speed sensor 2 Schematic Diagrams

Input shaft speed sensor 2 Description and Operation

Description • Components location : DCT (Dual Clutch Transmission) • Function The input shaft speed sensor is important in that it detects the input shaft RPM and sends this information to the Transmission Control Module (TCM)...

Input shaft speed sensor 2 Repair procedures

Removal 1. Remove the air cleaner assembly and air duct. (Refer to Engine Mechnical System - "Air cleaner") 2. Remove the battery and tray. (Refer to Engine Electrical System - "Battery") 3...
