Rear View Camera
The Rear View Camera will activate when the engine is running and the shift lever is in the R (Reverse) position.
This is a supplemental system that shows behind the vehicle through the navigation display while backingup.
WARNING
The Rear View Camera is not a safety device. It only serves to assist the driver in identifying objects directly behind the middle of the vehicle. The camera does NOT cover the complete area behind the vehicle.
WARNING
NOTICE
Always keep the camera lens clean. The camera may not work normally if the lens is covered with foreign matter.
Hyundai Sonata LF 2014-2019 Service Manual: DCT Control Module (TCM) Schematic Diagrams
1. TCM Connector and Terminal Function
2. TCM Terminal Function
Connector [A]
PinDescriptionPinDescription1Clutch Actuator (Clutch Motor 1 (ODD)_Phase V)17-2Clutch actuator (Clutch Motor 2 (EVEN) Phase V)18Clutch Actuator (Clutch Motor 1 (ODD)_HALL 1)3Select Actuator (Shift Solenoid 2 (EVEN)_Gr ...
Hyundai Sonata LF 2014-2019 Service Manual: Repair procedures
Adjustment
1.
After loosening the hinge (A) mounting bolt, adjust the hood (B) by moving it up or down, or right or left.
2.
Adjust the hood height by turning the hood overslam bumpers (C).
3.
After loosening the hood latch (D) mounting bolts, adjust the latch by moving it up or down, or ...
